IT6812 Impact Transmitter

IT6812 Impact Transmitter
Hover over image to zoom
Price: $1,348.00
Product ID : IT6812
Manufacturer: Metrix Instrument Company
Weight: 1.00 lbs
E-mail to a friend

Purchase

Description

The Model IT6812 Impact Transmitter uses a new technique to measure impact severity on reciprocating machinery.

Impact has been used successfully to measure mechanical looseness on large reciprocating compressors for several years. This new Impact Transmitter combines the benefits of this measurement with the convenience of 4-20 mA loop powered sensor technology.

It has a built-in piezoelectric crystal sensing element, and uses a timing function as part of it’s severity determination. An impact event counter and memory device is used to record events meeting a preset amplitude threshold level. The 4-20 mA signal represents the number of impact events above the threshold level that occur within a preset time window called the reset time.

Mechanical impacts are both measured and qualified within the transmitter. The result is a current output proportional to impact severity.

Metrix Impact Transmitters detect the following: loose rod nuts, cracked rods, broken or loose bolts, liquid in the process, loose or worn wrist pins, excessive clearance in the slipper, and other loose or broken parts. parts.parts.



SPECIFICATIONS
Sensor: Piezoelectric accelerometer with integral signal conditioner
Output Current: 4 to 20 mA, 2 wire
Impact Range: Output proportional to impacts over an adjustable time base of 0.8 to 3.2 sec. 16 impacts provides a full scale range (20mA)
Impact Threshold: 50mV to 1200mV
Case Material: 303 stainless steel
Mounting: Supplied with both 1/4"-28 and M6 threaded captive allen screws
Shock Limit: 5,000 g peak
Temperature Range: -40°C to +100°C
Sensitivity vs. Temperature: <.05%/°C
Cross Axis Response: Less than 5%
Loop Supply Voltage:  15 to 30 Vdc.
Maximum Load Resistance: 50 (Vs-15) ohms
Sealing: Welded construction with sealed adjustments
Electrical Connection: 2 pin MIL-C-5015 Style
Isolation: 500 Vrms, circuit to case
Hazard Rating: UL and cUL certified Class I, Div. 2, Groups A-D.  BASEEFA (Pending) Intrinsically Safe EEx ia IIB T4 (T amb = 100oC)
Environmental Rating: NEMA 4 / IP 65 (Pending)
Electromagnetic Compatibility: CE Mark (Pending)
