Description

Ideal for pulling medium to heavy loads; the L-type is fitted to the cable being pulled by stitching it together, like a football. Mainly used where a ‘typical’ cable grip can’t be fitted over a connector at the end of a cable.

Data Sheet

Stainless Steel Imperial

Slingco part no.	Reference	Size range	Lattice weave	Lattice length	Overall length	Approx breaking strength (lb)
ZCS1983	L1	0.25 - 0.50"	Single	9"	12"	1,344
ZCS1796	L2	0.50 - 0.75"	Single	14"	17"	1,792
ZCS1789	L3	0.75 - 1.00"	Single	16"	20"	4,480
ZCS1797	L4	1.00 - 1.50"	Single	18"	24"	6,272
ZCS1984	L5	1.50 - 2.00"	Double	21"	29"	8,960
ZCS2466	L6	2.00 - 2.50"	Double	24"	34"	8,960
ZCS0816	L7	2.50 - 3.50"	Double	27"	39"	10,752
ZCS1356	L8	3.50 - 4.50"	Double	27"	39"	12,544
ZCS1355	L9	4.50 - 5.50"	Double	27"	39"	12,544

Stainless Steel Metric

Slingco part no.	Reference	Size range (mm)	Lattice weave	Lattice length (mm)	Overall length (mm)	Approx breaking strength (kg)
ZCS1983	L1	10-13	Single	230	305	610
ZCS1796	L2	13-19	Single	355	430	813
ZCS1789	L3	19-25	Single	405	510	2,033
ZCS1797	L4	25-38	Single	455	610	2,846
ZCS1984	L5	38-50	Double	535	735	4,065
ZCS2466	L6	50-63	Double	610	865	4,065
ZCS0816	L7	63-89	Double	685	990	4,878
ZCS1356	L8	89-115	Double	685	990	5,691
ZCS1355	L9	115-140	Double	685	990	5,691
