F-Type (Offset Eye)

Hover over image to zoom

Price: $66.22

Product ID : F-Type (Offset Eye)

Manufacturer: Slingco

Weight: 1.00 lbs

Please complete this form.
All fields are required.

Your name

Your email address

Your friend's name

Your friend's email

The selected item is out of stock, please select a different item or combination

Similar to the S Type single eye cable grip, but for use when offset positioning is required and the cable passes completely through the cable grip.

Stainless Steel Imperial

Slingco part no.	Reference	Size range	Lattice weave	Lattice length	Overall length	Approx breaking strength (lb)
ZCS1986	OS1	0.25 - 0.50"	Single	9"	12"	1,344
ZCS1987	OS2	0.50 - 0.75"	Single	14"	17"	1,792
ZCS1988	OS3	0.75 - 1.00"	Single	16"	20"	4,480
ZCS1989	OS4	1.00 - 1.50"	Single	18"	24"	6,272
ZCS1990	OS5	1.50 - 2.00"	Double	21"	29"	8,960
ZCS1991	OS6	2.00 - 2.50"	Double	24"	34"	8,960
ZCS1992	OS7	2.50 - 3.50"	Double	27"	39"	10,752
ZCS1993	OS8	3.50 - 4.50"	Double	27"	39"	12,544
ZCS1994	OS9	4.50 - 5.50"	Double	27"	39"	12,544

Stainless Steel Metric

Slingco part no.	Reference	Size range (mm)	Lattice weave	Lattice length (mm)	Overall length (mm)	Approx breaking strength (kg)
ZCS1986	OS1	10-13	Single	230	305	610
ZCS1987	OS2	13-19	Single	355	430	813
ZCS1988	OS3	19-25	Single	405	510	2,033
ZCS1989	OS4	25-38	Single	455	610	2,846
ZCS1990	OS5	38-50	Double	535	735	4,065
ZCS1991	OS6	50-63	Double	610	865	4,065
ZCS1992	OS7	63-89	Double	685	990	4,878
ZCS1993	OS8	89-115	Double	685	990	5,691
ZCS1994	OS9	115-140	Double	685	990	5,691
